Urine Chemistry and Sediment Analysis
in One Analyzer


The Vcheck U urinary analyzer runs chemistry and sediment testing for canine and feline patients all in a single unit. This analyzer screens for 15 chemistry and 16 sediment parameters in just 4 minutes and produces individual images that provide veterinarians with detailed diagnostic information. Urine tubes can be loaded directly into the analyzer, and advanced AI is used for interpreting results, enhancing usability and efficiency.


Two Kinds of Analysis,
One Analyzer

While competitive urinary analyzers only focus on sediment, the Vcheck U covers chemistry and sediment analysis for the most complete diagnostic information.

​

Chemistry

  • The Vcheck U Chemistry strip can test 15 items.

  • It uses dipstick colorimetric tests with dual-wavelength reflectance photometry.

  • The measured parameters provide essential information for detecting metabolic issues, kidney function and urinary tract infections.

​

Sediment

  • The Vcheck U’s Sediment parameters can test 16 items — eight with quantitative and eight with semi-quantitative results.

  • Using AI recognition and digital imaging, Vcheck U analyzes elements such as red and white blood cells, epithelial cells and casts.

  • It also detects crystals, including calcium oxalate and uric acid crystals, and even bacteria and fungus.

  • These parameters offer a detailed view of sediment content, which is crucial for diagnosing infections, kidney stones and more.

Want to Schedule a Demo?

Contact us to schedule an in-person or virtual demo with your local sales representative.

Features

Automation for Sediment

  • Takes pictures with 40X magnification objective lens

  • Provides full field images and individual particle images

​

Easy Maintenance

  • Magnetic strip holder for easy load and unload

  • Auto focus without focus solution

  • Auto clean function

​

Simplified Testing Process

  • Integrated reagent pack for easy loading and unloading

  • Automatic registration when loading reagent

​

Less is More

  • Automated steps of skipping centrifugation, supernatant disposal, slide glass and staining keep the process efficient.



Utilizes AI Technology

Parameters

Sediment

  • Red blood cells

  • Dysmorphic red blood cells

  • White blood cells

  • Squamous Epithelial cells

  • Non-squamous Epithelial cells

  • Renal Tubular epithelium cells

  • Hyaline casts

  • Pathological casts

  • Calcium Oxalate crystals

  • Uric acid crystals

  • Struvite crystals

  • Unclassified crystals

  • Bacteria Rods

  • Bacteria Cocci

  • Fungus

  • Sperm

Chemistry

  • Leukocytes

  • Ketones

  • Urobilinogen

  • Bilirubin

  • Urinary protein

  • Glucose

  • Specific gravity

  • Blood

  • pH

  • Ascorbic acid
    (Vitamin C)

  • Urinary microalbumin

  • Urinary creatinine

  • Calcium

  • UPC

  • Nitrate

Need More Information?

Contact us for more information about the Vcheck U or any of our other tests and analyzers.

Specifications

Model
Vcheck U3
Sample Type
Urine
Species
Canine, Feline
Testing Time
Chemistry + Sediment 15 per hour
Storage
Up to 1 million results
Dimensions
18.3"w x 10.6"d x 15.9"h
Weight
39.7 lbs
